Inline Plasma Surface Treatment Machine VC-450
Inline Plasma Surface Treatment Machine VC-450
● Mobel: 1150D
● MOQ : 1 set
● Packing details:
● Subject to discussion:
Couldn't load pickup availability
Product overview Inline Plasma Surface Treatment Machine VC-450
The VC-450M Inline Plasma Surface Treatment Machine is an advanced non-vacuum plasma system designed for continuous, high-efficiency cleaning and activation of various materials. Using high-temperature and high-pressure ionized air plasma, the system removes organic contaminants, neutralizes static electricity, and improves surface energy — ensuring stronger adhesion, better coating performance, and higher production reliability.
Technical specifications
| Item | Specification |
|---|---|
| Model | VC-450M |
| System Type | Inline plasma surface treatment (non-vacuum) |
| Machine Size (W×D×H) | 800 × 1270 × 1450 mm |
| PCB Size | 50 × 50 – 450 × 400 mm |
| Processing Speed | 10 – 300 mm/s |
| Z-Axis Control | Software controlled, range 0–80 mm |
| Track Height | 900 ± 20 mm |
| Plasma Head | Single head, rotary spray import system |
| Power Consumption | 2.5 kW |
| Plasma Power | 600 – 800 W (max) |
| Discharge Voltage | 8 – 12 kV |
| Working Frequency | 40 kHz |
| Gas Flow | 40 L/min |
| Optimal Nozzle Height | 12 – 16 mm |
| Nozzle Options | Ø20 mm (standard), Ø40 / Ø60 optional |
| Power Supply | AC 220 V, 50/60 Hz |
| Control System | Industrial PC + servo system |
| Operating Software | VECTRON Control Software (EN/CH) |
| Safety | Real-time alarm for air pressure, power, and temperature |
Applications
Electronics & Semiconductor
PCB, FPC, wafer, and LED substrate surface activation
Mobile phone glass cover bonding
Chip encapsulation and conformal coating pretreatment
Automotive Industry
Headlight and interior trim bonding
EPDM weather strip surface activation
Automotive electronics and sensor module cleaning
Packaging & Printing
Plastic or paper box surface pretreatment before printing
Cosmetic and toy packaging adhesion enhancement
Textile & Footwear
Fabric and non-woven surface activation before dyeing or lamination
Shoe material gluing and printing enhancement
