B-800 Dispensing Controller

Technical Data:

→ Power consumption: 8W

→ Air source: max 0.99 Mpa   Pressure setting: 0.05-0.99 Mpa

→ Time setting: DIP switch 0.01-1s; 0.1-10s; 0.2-20s; 0.3-30s

→ Control mode: Manual / Quantitative (fixed volume dispensing)

→ Repetitive accuracy: ± 0.05%   Dispensing frequency: 600/min

→ Min. dispensing volume: 0.01 ml

→ Dimension: 235mm x 225mm x 63mm     Weight: 2.2 Kg

Applications:

→ Materials for dispensing:

   solder tin, tin paste, UV adhesive, lubricant, epoxy resin,

   fast cure adhesive, silicone resin, etc.

→ Usage: adhering, fixing, dot coating, line coating, etc
