Automatic CO₂ Liquid Cleaning Machine CTS-COSM201
Automatic CO₂ Liquid Cleaning Machine CTS-COSM201
● Mobel: 1150D
● MOQ : 1 set
● Packing details:
● Subject to discussion:
Couldn't load pickup availability
Product overview
The CO₂ liquid Cleaner is a high-performance cleaning system that utilizes liquid CO₂ jet technology to remove microscopic contaminants from sensitive surfaces. Unlike traditional dry ice blasting, this system uses pressurized liquid carbon dioxide to deliver a gentler yet highly effective cleaning action — ideal for precision industries such as semiconductor, display panel, and PCB manufacturing.
By combining physical jet impact, thermal shock, and sublimation expansion, the CO₂ liquid Cleaner ensures efficient removal of organic and inorganic particles without moisture, abrasion, or residue, making it a preferred choice for cleanroom environments.
Technical specifications
| Item | Specification |
|---|---|
| Model | JIT C1 |
| Voltage | AC 220 V (50–60 Hz) |
| Power | 300 W |
| Weight | 50 kg |
| Dimension | 565 × 365 × 510 mm |
| Dry Ice Capacity | 5 kg |
| Dry Ice Flow / Working Air Pressure | 0–1.0 kg/min / 0.2–0.6 MPa (adjustable) |
Applications
Semiconductor manufacturing: Wafer, CP/FT process cleaning
Display industry: Glass substrate and panel surface cleaning
Electronics assembly: PCB and micro-component cleaning
Optical and precision devices: Lens and optical part cleaning in cleanrooms
